MS310T UV Sterilization Dual Tray Incubator Shaker

short description:

Use

For shaking culture of microorganism, it’s UV sterilization incubator shaker with dual tray.


Product Detail

Product Tags

Key Features:

❏ The dual tray offers two shaking levels and doubles the capacity
▸ Dual tray inside the chamber, effectively extending the culture space without increasing the laboratory footprint.

❏ 7-inch LCD touch panel controller, intuitive control and easy operation
▸ 7-inch touch screen control panel is intuitive and easy to operate, so you can easily control the switch of a parameter and change its value without special training
▸ 30-stage program can be set up to set different temperature, speed, time and other culture parameters, and the program can be automatically and seamlessly switched between; any parameters and historical data curve of the culture process can be viewed at any time

❏ Sliding black window can be supplied for avoid light cultivation (Optional)
▸ For light-sensitive media or organisms, the sliding black window prevents sunlight (UV radiation) from entering the interior of the incubator, while retaining the convenience of viewing the interior of the incubator
▸ Sliding black window is positioned between the glass window and the outer chamber panel, making it convenient and aesthetically pleasing, and perfectly solving the inconvenience of applying tin foil

❏ Intelligent remote monitor function, remote control operation, real-time view of machine operation status (Optional)
▸ Intelligent remote control allows you to control the parameters of the incubator more easily

❏ Double glass doors for excellent insulation and safety
▸ Double glazed interior and exterior safety doors for excellent thermal insulation

❏ Door heating function prevents fogging of the glass door and allows observation of cell culture at all times (Optional)
▸ Door heating function effectively prevents condensation on the glass window, allowing good observation of the shaker when the temperature difference between the inside and outside is large

❏ UV sterilization system for better sterilization effect
▸ UV sterilization unit for effective sterilization, UV sterilization unit can be opened during rest time to ensure a clean culture environment inside the chamber.

❏ Brushed full stainless steel rounded corners of the integrated cavity, beautiful and easy to clean
▸ Waterproof design of the incubator body, all water or mist-sensitive components including drive motors and electronic components are placed outside the chamber, so the incubator can be cultivated in high temperature and high humidity environment
▸ Any accidental breakage of bottles during incubation will not damage the incubator, and the bottom of the incubator can be cleaned directly with water or thoroughly cleaned with cleaners and sterilizers to ensure a sterile environment inside the incubator

❏ Machine operation is nearly silent, multi-unit stacked high-speed operation without abnormal vibration
▸ Stable start-up with unique bearing technology, almost noiseless operation, no abnormal vibration even when multiple layers are stacked
▸ Stable machine operation and longer service life

❏ One-piece molding flask clamp is stable and durable, effectively preventing unsafe incidents due to clamp breakage
▸ All of RADOBIO's flask clamps are cut directly from a single piece of 304 stainless steel, which is stable and durable and will not break, effectively preventing unsafe incidents such as flask breakage
▸ The stainless steel clamps are plastic sealed to prevent cuts to the user, while reducing friction between the flask and the clamp, bringing a better silent experience
▸ Various culture vessel fixtures can be customized

❏ Waterproof fan without heat, significantly reducing background heat and saving energy
▸ Compared with conventional fans, heatless waterproof fans can provide a more uniform and stable temperature in the chamber, while effectively reducing background heat and providing a wider range of incubation temperatures without activating the refrigeration system, which also saves energy

❏ 8mm aluminum alloy sliding tray for easy placement of culture flasks
▸ 8mm thick aluminum alloy sliding tray is lighter and stronger, never deforms and is easy to clean
▸ Push-pull design allows for easy placement of culture flasks at specific heights and spaces

❏ Multi-safety design for operator and sample safety
▸ Optimized PID parameter settings that do not cause temperature overshoot during temperature rise and fall
▸ Fully optimized oscillation system and balancing system to ensure that no other unwanted vibrations occur during high speed oscillation
▸ After an accidental power failure, the shaker will remember the user's settings and automatically start up according to the original settings when the power comes back on, and automatically alert the operator of the accident that has occurred
▸ If the user opens the hatch during operation, the shaker oscillating plate will automatically brake flexibly until it stops oscillating completely, and when the hatch is closed, the shaker oscillating plate will automatically start flexibly until it reaches the preset oscillating speed, so there will be no unsafe events caused by sudden speed increase.
▸ When a parameter deviates far from the set value, the sound and light alarm system is automatically turned on
▸ Touch screen control panel with data export USB port on the side for easy export of backup data and convenient and safe data storage

Configuration List:

Incubator Shaker 1
Dual Tray with Holder 1
Fuse 2
Power Cord 1
Product Manual, Test Report, etc. 1

 Technical Details

Model MS310T
Control interface 7.0 inch LED touch operation screen
Rotation speed 2~300rpm depending on load and stacking
Speed control accuracy 1rpm
Shaking throw 26mm (Customization is available)
Temperature control mode PID control mode
Temperature control range 4~60°C
Temperature display resolution 0.1°C
Temperature distribution ±0.5°C at 37°C
Principle of temp. sensor Pt-100
Power consumption max.
1300W
Timer 0~999h
Tray size 500×500mm (dual tray)
Maximum load 35kg
Tray capacity of shake flask (25×250ml or 16×500ml or 9×1000ml)×2 (standard with Interwoven springs, Other holders are available)
Dimension (W×D×H) 710×776×1080mm
Internal dimension (W×D×H) 680×640×692 mm
Volume 310L
Illumination FI tube,30W
Sterilization method UV sterilization
Number of settable programs 5
Number of stages per program 30
Data export interface USB interface
Historical data storage 250,000 messages
Ambient temperature 5~35°C
Power supply 115/230V±10%, 50/60Hz
Weight 160kg
Material incubation chamber Stainless steel
Material outer chamber Painted steel
Optional item Sliding black window; Remote monitoring

*All products are tested in controlled environments in the manner of RADOBIO. We do not guarantee consistent results when tested under different conditions.

Shipping Information

Cat.No. Product name Shipping dimensions
(W×D×H) (mm)
Shipping weight (kg)
MS310T UV Sterilization Dual Tray Incubator Shaker 800×920×1260 205
